Run Length
|
:
|
300 - 400 m
|
|
Drag Hose Size
|
:
|
2.5" or 3"
|
|
Sprinkler
|
:
|
DuCaR JET 55
|
|
Effective Spray Width
|
:
|
50M - 70M
|
|
Flow Rate
|
:
|
383 - 665 l/min
|
|
Required Pressure Rate
|
:
|
60 - 90 psi
|
|
Traveller Speed
|
:
|
10 - 70 m/hour
|
|
Weight
|
:
|
550 kg
|
|
Standard Equipment
|
:
|
Manual Brake system, High Efficiency Water Turbine, PTO Driven Purge Pump, Galvanized Main Body with Powder Coating paint
|
|
Run Length
|
:
|
300 m
|
|
Drag Hose Size
|
:
|
2.5"
|
|
Sprinkler
|
:
|
DuCaR JET 55
|
|
Effective Spray Width
|
:
|
50M - 90M
|
|
Flow Rate
|
:
|
300 - 750 l/min
|
|
Required Pressure Rate
|
:
|
40 - 90 psi
|
|
Traveller Speed
|
:
|
10 - 60 m/hour
|
|
Weight
|
:
|
650 kg
|
|
Standard Equipment
|
:
|
Manual Brake system, High Efficiency Water Turbine, PTO Driven Purge Pump, Galvanized Main Body with Powder Coating paint
|
|
Cable Length
|
:
|
200 m
|
|
Lay Flat Hose
|
:
|
2" 100 m Premium Drag Hose
|
|
Working Pressure
|
:
|
45 - 75 psi
|
|
Water Flow
|
:
|
150 - 500 l/min
|
|
Effective Spray Width
|
:
|
40 - 70 m
|
|
Total Irrigated Area
|
:
|
225 X 350 m = 78,750 m² (~8 Hectare) in 7 days
|
|
Sprinkler
|
:
|
DuCaR Atom 40
|
|
Mechanism
|
:
|
Turbine drive & Automatic Stop at End of Run
|
|
Weight
|
:
|
150 kg
|
|
Construction
|
:
|
Heavy duty welded chassis all hot dip galvanized
|
|
Cable Length
|
:
|
120 m
|
|
Lay Flat Hose
|
:
|
1 1/4" (32 mm) 60 m Premium Drag Hose
|
|
Working Pressure
|
:
|
30 - 51 psi
|
|
Water Flow
|
:
|
57 - 117 l/min
|
|
Effective Spray Width
|
:
|
30 - 40 m
|
|
Travel Speed
|
:
|
19 to 110 m/h
|
|
Sprinkler
|
:
|
DuCaR Atom 22
|
|
Mechanism
|
:
|
Turbine drive & Automatic Stop at End of Run
|
|
Weight
|
:
|
55 kg
|
|
Construction
|
:
|
Heavy duty welded chassis hot dip galvanized & powder coated
|
|
Run Length
|
:
|
400 M
|
|
Lay Flat Hose
|
:
|
3.5" 200 m Premium Drag Hose
|
|
Working Pressure
|
:
|
70 - 100 psi
|
|
Water Flow
|
:
|
700 - 1400 l/min
|
|
Effective Spray Width
|
:
|
70M - 120M
|
|
Total Irrigated Area
|
:
|
445 X 630 m = 280,350 m² (28 Hectare) in 7 days
|
|
Speed
|
:
|
10 - 70 m/hour
|
|
Sprinkler
|
:
|
DuCaR Green 150
|
|
Mechanism
|
:
|
Turbine drive, BIMA 3-Speed Gear Box & Automatic Travel Shut Off
|
|
Weight
|
:
|
1200 kg
|
|
Construction
|
:
|
Heavy duty welded chassis with rust proof and hot dip galvanised frame and reel
|
